Nitto Trail Grappler SxS
Nitto Trail Grappler SXS
The Nitto Trail Grappler SXS is a UTV tire developed to compete in the King of Hammers, the ultimate off-road proving grounds. Inspired by the Trail Grappler M/T, this rugged tire dominates anywhere you take it. Its features include:
Designed to bring the Trail Grappler M/T’s durability and performance to side-by-sides, this tire has a true off-road racing pedigree.
Built for one of the toughest off-road competitions out there, this UTV tire has been tested in the harshest conditions by off-road champions.
This tire can tango with every type of off-road challenge, from high speed desert runs to highly technical rock crawling.
With its 3D computer-simulated tread design, it’s engineered specifically for side-by-side use.
With Nitto’s proprietary automated manufacturing system that produces uniform tires, it offers consistent handling regardless of the terrain.
This mini-me offers the same rugged durability of the Grappler M/T.
A balanced void ratio efficiently removes mud and dirt from the tread to deliver constant off-road grip.
This tire offers a narrower footprint (only 9.5”) to maintain steering and agility, even in aired down applications, so you stay in control.
Reinforced sidewalls offer puncture resistance, so you can roll over any obstacle.
Available in 15” sizes, this tire should fit most major side-by-side brands and models.
UNIFORM TIRE QUALITY GRADE (UTQG)Uniform Tire Quality Grade
| SECTION WIDTH Measures the width of the tire from sidewall to sidewall, which is mounted on a wheel and inflated. | 30 - 35 |
| ASPECT RATIO Determines the sidewall height of the tire, based on the width. | 9.5 |
| RIM DIAMETER Measures the rim size from top to bottom (in inches). | 15" |
| OVERALL DIAMETER Measures the tire height from top to bottom when mounted on a wheel and inflated. | 29.76" - 34.53" |
| RIM WIDTH RANGE The approved range of rim widths this tire can be safely mounted on. | 6.0" - 8.5" |
| WEIGHT The weight of the tire measured in pounds (weight of tire only). | 39.0 LBS - 57.0 LBS |
| TREAD DEPTH Measured in /32 of an inch to determine the height of the tread block from top to bottom. | 18/32" |
| LOAD INDEX Determines the weight a tire can carry at maximum air pressure. See load Index chart. | 96 - 108 |
| LOAD RANGE Determines the ply rating of the tire. Should be replaced with the same or higher rating. | BP - DP |
| MAX PSI The max psi is the highest pressure the tire can hold, but should be inflated to your vehicle specifications not exceeding this amount. | 35 PSI |
| SIDEWALL DESC. The sidewall designation to describe the lettering on the sidewall. | Black Side Wall |
| VPN Vendor Product Number | 207460 - 209500 |
